US $147.11
Original Price : US $171.06 (14%)
Cheap Offer DIY Full Kit DIY Mini Racing Drone 310 Fiberglass Frame Racer Helicopter MICRO F3 Flight Controller with FREE Shipping Worldwide!
4.46
Related Products :
M4 M5 M6 Hand Tighten Screw Aluminum Alloy Handle Adjustable Screws DSLR Camera Photography Accessories
XILETU XJ-8 Tripod phone tripod mount Head Bracket Mobile Phone Holder Clip For Phone Flashlight Microphone With Spirit level
JEYI VolleyStar-PRO Black Heat Sink Heatsink M.2 NVMe SSD NGFF TO PCIE X4 Adapter MKey Port Card PCI-E 3.0 x4 Full Speed RGB LED
Aluminum L-type Adjustment Tighten Locking 7-shaped Handle Screw M5 M4 Adjustable Screws DSLR Camera Photographic Parts
Product description
[32738561320]Full Kit DIY Mini Racing Drone RC Drone RacerFiberglassFrame Multicopter MICRO F3 Flight Controller AT9S FS-i6 Transmitter
DIY RTF set,compatable with different transmitter,with/without battery and charger,please feelfree to choose the version you prefer,thanks
Please Note :
With AT9Transmitter KIT Upgrade to AT9S Transmitter .
Specifications:frame in light weight, the conventional FPV configuration as a whole take-off weight can be controlled at about 500 gramsgeneral configuration 5"-10" propeller (Not inclued)Personality Across Design,Material: Fiberglass Frame kitFramereference:Motor: MT2204 or MT2206Propellers:2204 motor use FC 5"-6" blade2206 motor use FC 5" 6" 8" bladeESC: 15A-20AVoltage: 11.V-11.8VWeight about: 200gXT-XINTE 920KVMotor:Outer diameter: 28.0 mm
Height: 24.0 mm (Without Shaft)
K V: 920kv
Fit for DJI Phantom 3-4s F330 F450 F550 X525 DIY Quadcopter Cheerson CX-20 Drone
Hobbywing XRotor 20A 2-3S ESC:
1.1 Rotor dedicated program, fast throttle response, beyond the various types of open source software;
1.2 Specifically optimized firmware disc motor, the motor has a very good compatibility;
1.3 Highly intelligent, adaptive ability, extremely easy to use;
1.4 Throttle signal line is a twisted pair, copper wire to reduce crosstalk signal generated within the transmission, so that more stable flight;
1.5 Supports up to 621Hz refresh rates up to the throttle signal, compatible with a variety of flight control (Note: More than 500Hz signal of the throttle throttle are all non-standard signal)
1.6 Use MOSFET special driver chip, performance and stability far beyond the driving circuit with discrete components built
1.7 Ultra-low resistance MOSFET, strong resistance to current capacity;
1.8 Exquisite plastic case back with high brightness LED navigation lights
1.9 Power transfer comes on the back of the micro DIP switch for setting LED navigation lights on / off, LED light color, into the steering angle and the motor.
Radiolink AT9S OR Flysky FS-I6Transmitter Specfications:
< Radiolink AT9S Transmitter>
1. Size: AT9S- 183*100*193mm, R9DS- 41*23*14mm2. Weight: 0.88kg3. Frequency: 2.4GHz ISM band (2400MHz to 2483.5MHz)4. Modulation mode: QPSK5. Channel bandwidth: 5.0 MHz & 250Kbps6. Spread spectrum: DSSS ;FHSS7. Adjacent channel rejection: >38dbm8. Transmitter power: <100mW (20dbm )9. Operating current: <90mA 12V10. Operating voltage: 7.4 ~ 18.0V11. Control distance: more than 900 meters ground, 1500 meters air, the actual control distance depends on the flying environment12. Channel: 10 channels, 5-10 channels are customized13. Compatible model: include all 120 degree and 90 degree swash-plate helicopter, all fix wings, glider and multi-rotor14. Simulator mode: under the simulator mode the transmitter action turn off, change to power saving mode15. Screen: 2.8 inches 16 colorful screen, 240*320 pixels16. Support receivers: sells with R9DS (SBUS;PWM) ;Also support R10DS(SBUS PWM) and R6DS(SBUS;PPM;PWM)
< Flysky FS-I6 Transmitter>
Reliable, interference free 2.4GHz AFHDS 2A signal operation.
6CH operation.
Use only 4 * AA batteries for transmitter.
Quick and extremely stable in performance.
Simple binding procedure.
Highlights:
Works in the frequency range of 2.405 to 2.475GHz.This band has been divided into 142 independent channels,each radio system uses 16 different channels and 160 different types of hopping algorithm.Silm design on transmitter for easy handling!
This radio system uses a high gain and high quality multi directional antenna,it covers the whole frequency band. Associated with a high sensitivity receiver,this radio system guarantees a jamming free long range radio transmission
Each transmitter has a unique ID,when binding with a receiver,the receiver saves that unique ID and can accepts only data from the unique transmitter.this avoids picking another transmitter signal and dramatically increase interference immunity and safety.
This radio system uses low power electronic components and sensitive receiver chip.The RF modulation uses intermittent signal thus reducing even more power consumption.
AFHDS2A system has the automatic identification function,which can switch automatically current mode between single-way communication mode and two-way communication mode according to the customer needs.
AFHDS2A has built-in multiple channel coding and error-correction,which improve the stability of the communication,reduce the error ratio and extend the reliable transmission distance.
Package listing:
<with AT9S TX Full Kit>
1*Fiberglass310Alien Across Mini Quadcopter DIY Frame Kit
4*XT-XINTE 920KV CW CCW Brushless Motor( 2 CW and 2 CCW motor )
4*Hobbywing XRotor 20A 2-3SESC
1*Mini Power Hub Power Distribution Board PDB with BEC
1*XT-XINTE 6DOF MICRO F3 flight control board
2*8045 plastic self-lockingpropeller(black and white color,4 pairs in total)
1*Radiolink AT9S 2.4GHz 9 Channel Transmitter& Receiver
1* XT-XINTE11.1V2200MAH20C lipo battery
1*B3 Pro Compact Balance Charger
1*BX100LiPo Battery Voltage Checker
1*140MM High Landing Gear Skid
1* Tool kit
<with 6CH TX Full Kit>
1*Fiberglass310Alien Across Mini Quadcopter DIY Frame Kit
1*Flysky FS-i6 6CH 2.4G AFHDS 2A LCD Transmitter iA6 Receiver
<No battery 9CH TX>
<No battery 6CH TX>
