US $172.9
Original Price : US $190 (9%)
Best Offer DIY RC Drone Quadcopter ARF X4M360L Frame Kit with QQ Super Flight control Motor ESC FS-i6 Transmit with Free Worldwide Shipping!
4.76
Related Products :
Plastic Tighten Thomb Knob Bolt Nut Screw Wrench Spanner Tool w/ Safety Rope for Gopro Hero 7 6 5 4 3 3 Plus Camera Mount
JMT 4Pcs/Kit Propeller Guards Protector Prop Blades Protection Cover for DJI TELLO Propeller Drone Quadcopter Accessory
Mini Detachable Tripods Mount Adapter for Gopro Hero 3+ Plus 3 2 Monopod/XIAOYI /XIAOMI + F08817
M4 M5 M6 Hand Tighten Screw Aluminum Alloy Handle Adjustable Screws DSLR Camera Photo Studio Accessory
Product description
[32805765444]DIY RC Drone Quadrocopter ARFX4M360L Frame Kit with QQ Super flight control Motor ESC 2.4G FS-i6 Transmitter 11.1V 3300Mah 25C Battery
Package include:
1xX4M360L frame
2x920KV CW Brushless Motor
2x920KV CCW Brushless Motor
4x30A Brushless ESC
2X8443 8.4*4.3" Carbon Fiber Propeller Self-locking Props
1XMK KK Multi-Copter Power Battery to 8 ESC Connection Board
1XQQ Super Flight control
12x3.5mm banana plug
1xDeans Style T Plug Male Connector Silicone Wire With 11.5CM 14awg
1xHook and & Loop Fastening Tape
1XFlysky FS-i6 6CH 2.4G AFHDS 2A LCD Transmitter iA6 Receiver
1X11.1V 3300Mah 25C Battery
1x IMAX RC B3 Pro Compact Balance Charger
Multi-rotor flight control
Built-in three-axis gyroscope and three-axis acceleration sensor, support for self-stabilizing, super stable flight performance
Support the general receiver, FUTABA S.BUS receiver, DSM2, 11MS, 22MS receiver, simplifying connection installation more convenient, ultra-bright LED
Product Specifications:
Processor:32BIT ARM
Voltage:3.6V-8.4V
Current:60mA*
Output rate:360Hz
Dimension(L-W-H):43X29X13MM
Weight:13g
Not include receiver and satelite
Reliable, interference free 2.4GHz AFHDS 2A signal operation.
6CH operation.
Use only 4 * AA batteries for transmitter.
Quick and extremely stable in performance.
Simple binding procedure.
Highlights:
Works in the frequency range of 2.405 to 2.475GHz.This band has been divided into 142 independent channels,each radio system uses 16 different channels and 160 different types of hopping algorithm.Silm design on transmitter for easy handling!
This radio system uses a high gain and high quality multi directional antenna,it covers the whole frequency band. Associated with a high sensitivity receiver,this radio system guarantees a jamming free long range radio transmission
Each transmitter has a unique ID,when binding with a receiver,the receiver saves that unique ID and can accepts only data from the unique transmitter.this avoids picking another transmitter signal and dramatically increase interference immunity and safety.
This radio system uses low power electronic components and sensitive receiver chip.The RF modulation uses intermittent signal thus reducing even more power consumption.
AFHDS2A system has the automatic identification function,which can switch automatically current mode between single-way communication mode and two-way communication mode according to the customer needs.
AFHDS2A has built-in multiple channel coding and error-correction,which improve the stability of the communication,reduce the error ratio and extend the reliable transmission distance.
ransmitter Specfications:
Channels: 6
Model type: fixed-wing/glider/helicopter
RF range: 2.405-2.475GHz
Bandwidth: 500KHz
Band: 142
RF power: less than 20dBm
2.4G system: AFHDS 2A and AFHDS
Code type: GFSK
Sensitivity: 1024
Low voltage warning: less than 4.2V
DSC port: PS2; output: PPM
Charger port: no
ANT length: 26mm * 2(dual antenna)
Power: 6V 1.5AA * 4 (Not included)
Display mode: Transflective STN positive type,
128 * 64 dot matrix VA72 * 39mm, white backlight.
Size:174 * 89 * 190mm
Weight: 392g
Online update: yes
Color: black
Receiver Specifications:
Channels: 6 Channels
Model type: Airplane / Glider / Helicopter
Frequency range: 2.4--2.48GHZ
Band width number: 140
Transmitting power: not moer than 20dBm
RX sensitivity: -105dBm
2.4G system: AFHDS 2A
Code type: GFSK
Antenna length: 26mm
Input power: 4.0-6.5V DC
Dimension: 40 * 21 * 7mm
Weight: 6.4g
Color: Black
i-Bus interface: No
Data acquisition interface: No
