Limited Offer Videopass 1.4G Video Downlink for uav multirotor VTOL fixed wing cover range 20km to 30km FPV trans with FREE Worldwide Shipping!
4.69
Related Products :
Fixed Wing VTOL drone 2.5kg payload 2.5hour endurance long range uav for inspection survey aerial photography earch
MyFlyDream MFD Nimbus 1800mm Long Range VTOL fixed-wing UAV RC FPV Plane Almost Ready to Fly Aircraft for Mapping and Survey
Hybrid Fixed Wing VTOL drone 4 to 8hour endurance long range uav for inspection survey aerial photography agriculture search
Hybrid drone 3hours endurance and 8kg take off uav for inspection security and surveillance
Product description
[33051859985]Watch more videos from:
https://youtu.be/W98uqNtnLyY
About shipping:
This product is Free Shipping and shipped by fast express, including DHL, TNT, Fedex, SF or other fast express depends on your country.Normally, the estimated delivery time is 3~7 days.
Your purchase includes:
1x Videopass air Transmitter(20~30km)
1x Videopass ground Receiver
1x Adjust device for air part
2x Antenna
2x Power cable
1x data transmit cable
1x Omni Antenna(including cable)
Please contact the sales when need to customizethe frequency and transmitdistance.
Introduction
Videopass is a long-range HD video and data transmission system, using H.264 video compression and COFDM modulation which provides robust, secure, and reliable video transmission over long ranges. The HD video link comes with low latency, low power consumption, and broadcast video quality real-time imaging, is ideal for UAV missions like surveillance, search and rescue.
Transmission range customizable
Videopass accepts range customization from 20KM to 200KM.
Transmitter power adjustable
Take 20-30KM version Videopass for example, when the transmission range cannot reach 20-30KM due to the interruption around, then you just need to switch toa higher power like -3dB(1.3 watt) on the config panel.
Frequency customizable
The long-range transmitter accepts frequency customization to adapt to local regulations.
Military-grade security
Videopass adopts AES encryption, and password setting can be easily done on the config panel.
Versatile output options
The HD video link provides three video output ports: HDMI, SDI, and CVBS. Meanwhile, audio can be transmitted too.
Easy configuration
Videopass wireless transmitter comes with one config panel with screen, and parameter setting can be quickly done there, like frequency, bandwidth, transmitter power, and password.
Specification
Transmitter(20-30KM version)
Power supply
DC12V/900mA
Video Compression
H.264
AV input
HDMI
Resolution
1080i/1080P@60fps, 720P, D1
Data serial port
TTL,one-way communication
Parametercontrol
Manual setting by the control buttons
Baud rate
19200bps
Power switch
ON/OFF simple operation
Frequency
1400MHz (customizable)
RF Interface
SMA
Bandwidth
2/2.5/4/8MHz(customizable)
Video formats
PAL/NTSC(self-adaption)
RF power
1Watt(0.8/1.3/1.6 watt optional)
Working temperature
-20℃～75℃
Encryption
AES - user defined password
Dimension
82*60*32mm
Modulation
COFDM,2K,QPSK
Weight
220grams
Receiver(20-30KM version)
Frequency
Paired with transmitter
RF Interface
N F head (50Ω)
RF bandwidth
2/2.5/4/8MHz(adjustable)
FEC
1/2 2/3 3/4 7/8
Receive sensitivity
-105dBm/2MHz,
-95dbm/4MHz/8MHz
Guard Interval
1/32 1/16 1/8 1/4
Working Voltage
DC12V
Resolution
1080i/1080P, 720P, D1
Working current
1.5A
Data Encryption
AES user-defined password
Power consumption
≤20W
Video format
PAL/NTSC(self adaption)
Modulation
COFDM 2K QPSK
Work environment
-30~70℃
Constellation
QPSK, 16QAM, 64QAM
Weight
1420 grams
AV Interface
HDMI/BNC
Size
700*460*58mm
Audio channel
Stereo left and right channels
